PDP-507XD
167
5678
56
7
8
C
D
F
A
B
E
9.3.2 QS2
Data Arrangement
Data
Length
Output Example
ECO 3 byte QS2
1 Notification of mode shifting to STB 1 byte 1
2 Flag for adjustment of the main unit 1 byte 0
3 Flag for adjustment-data backup 1 byte 0
4 "1st PD" data 1 byte 0
5 "2nd PD" data 1 byte 0
6 Still picture detection 1 byte 0
7 Reserved 2 byte ∗∗
8 Temperature data (TEMP 1) 3 byte 128 (*1)
9 SD main data 1 byte 0
10 SD sub data 1 byte 0
11 Operation status induced by SD 1 byte 0
12 Data from the hour meter 8 byte 00000259 (*2)
13 MASK indication 1 byte 0
CS 2 byte 4A
1: Notification of mode
shifting to Standby
0
Entering Standby
mode failed
1
Entering Standby
mode succeeded
2: Adjustment of the
main unit
0 Adjustment completed
1
Adjustment not
completed
3: Adjustment-data
backup
0 With backup data
1 No data (default)
6: Still picture detection
0 Normal screen
1 Still picture
4, 5: PD data
0 No PD data
1 Not used
2 POWER
3 SCAN
4 SCN-5V
5 Y-DRV
6 Y-DCDC
7 Y-SUS
8 ADRS
9 X-DRV
A X-DCDC
10-1: SD-Sub (SQ-IC)
0 No SD-Sub data
1 Communication error
2 Drive stop
3 BUSY
6 Version mismatching
B X-SUS
C Not used
D Not used
E Not used
F UNKNOWN
9: SD main data
0 No SD
1 SQ-IC
2 MDU-IIC
3 RST2
4 TEMP
11: Operation status
induced by SD
0 Normal
1 Relay-off completed
2
During warning
indication
13: MASK indication
0 MASK-OFF
1 MASK-ON
Command
Format
Effective Operation
Modes
Function Remarks
[QS2] All operations To acquire data on operations of the panel Return data: 3 (ECO)+23(DATA)+2(CS)= 28 Byte
The command QS2 is for acquiring data on the panel's operational information.
Note : (*1) The unit scale is centigrade. The data is A/D value from the
thermal sensor.
(*2) "00000259" of "Data from the hour meter" means
2 hours 59 minuts.
10-2: SD-Sub (IIC)
0 No SD-Sub data
1 EEPROM
2 BACKUP
3 DAC
10-3: SD-Sub (TEMP)
0 No SD-Sub data
1 TEMP1
2 Reserved
