Pioneer PDP-507XD Service Manual

PDP-507XD
172
1234
1234
C
D
F
A
B
E
9.3.9 QS6
9.3.10 QMT
Data ArrangementPartOrder
Data
Length
Remarks
Received Command name 3 byte QS6
01
00 −
−
DTB version 4 byte
02 Reserved 8 byte
03 TELE-TEXT version 60 byte
04 USER PASSWORD 4 byte
05 Check Sum 2 byte
Command
Format
Effective Operation
Modes
Function Remarks
[QS6] Every time Output of status
Induce it peculiar, individual information is acquired.
Data ArrangementPartOrder
Data
Length
Remarks
Received Command name 3 byte QMT
0: STOP 1: LOW, 5: HIGH, 3: MIDDLE (FHD only)
01
0 −
MTB
MTB-side Temperature (TEMP2) 3 byte
02 MTB-side FAN rotating speed 1 byte
Command
Format
Effective Operation
Modes
Function Remarks
[QMT] Every time Output of status MTB-side's temperature/FAN rotating status
Temperature information (TEMP2) / FAN rotation state information on the MTB side is returned.
