PDP-507XD
153
5678
56
7
8
C
D
F
A
B
E
8.2.3 OPTION
8.2.4 INITIALIZE
Operation item
8.2.3.1 EDID WRITE MODE
Exclusively used for production line.
8.2.3.2 CH PRESET
Exclusively used for production line.
No. Function Content RS-232C
1 EDID WRITE MODE ⇔ DISABLE ⇔ ENABLE −−−
2 CH PRESET ⇔ USER ⇔ FACTORY −−−
8.2.4.1 SYNC DET (+)
Exclusively used for technical analsyis (details omitted).
8.2.4.2 SG MODE
SG MODE (SG's route selection) / SG PATTERN (signal pattern selection) are used as pair.
In SG MODE, select the SG route and then select the SG pattern to be sent by the selected route.
In SG MODE, make sure to select the route first.
Operation item
No. Function Content RS-232C
1 SYNC DET (+) Exclusively used for technical analsyis. −−−
2 SG MODE ⇔ Paired SG_MODE with SG_PATTERN. Select SG Route. −−−
3 SG PATTERN ⇔ Paired SG_MODE with SG_PATTERN. Select SG Pattern. −−−
4 SIDE MASK LEVEL (+) Configure the color of the side mask. BSL, GSL, RSL
5 FINAL SETUP (+) Initialize flash memorys on virgin product status FST
6 CVT AUTO ⇔ Exclusively used for technical analsyis. −−−
7 HDMI INTR POSITION (+) Exclusively used for technical analsyis. −−−
Operation item
NIITI
GSANA–MVDEC–YMO E < = >D
LAIZE
A–V1 3 1060 –NTV HE–B7
1
5
10
15
16
15 10 15 20 25 30 35 40
No.
Display
Content
1 SG OFF SG Mode is OFF.
2 DIG MVDEC YCBCR MAIN VDEC: YCbCr
(Digital output mode)
3 ANA MVDEC Y MAIN VDEC: Y (Analog output
mode: SG VDEC return setting)
4 ANA MVDEC RGB MAIN VDEC:RGB
5 ANA SVDEC Y SUB VDEC:Y
6 ANA AD YCBCR AD: YcbCr
(Analog output to the RGB SW)
7 ANA AD RGB AD: RGB
(Analog output to the RGB SW)
To Next Page
