PDP-507XD
154
1234
1234
C
D
F
A
B
E
NIITILAIZE
GSPATERNT<=>
A–V1 3 1060
L
CO OR 1BAR
–NTV HE–B7
1
5
10
15
16
15 10 15 20 25 30 35 40
No. Display
SG Pattern (Brightness
IRE Level/Color)
No. Display
SG Pattern (Brightness
IRE Level/Color)
1 COLOR BAR1 Colorbar (75%) 11 RASTER4 Raster (75% Green)
2 COLOR BAR2 Colorbar (100%) 12 RASTER5 Raster (75% Magenta)
3 RAMP1 Ramp (100% white) 13 RASTER6 Raster (75% Red)
4 RAMP2 Ramp (100% Yellow) 14 RASTER7 Raster (75% Blue)
5 RAMP3 Ramp (75% Green) 15 RASTER8 Raster (– % Black)
6 RAMP4 Ramp (75% Red) 16 10STEP1 10STEP (100% white)
7 RAMP5 Ramp (75% Blue) 17 10STEP2 10STEP (100% Yellow)
8 RASTER1 Raster (100% White) 18 10STEP3 10STEP (75% Green)
9 RASTER2 Raster (75% Yellow) 19 10STEP4 10STEP (75% Red)
10 RASTER3 Raster (75% Cyanide) 20 10STEP5 10STEP (75% Blue)
• During factory mode, choose the correct route when changing.
• Basically, during VDEC SG output, make sure to connect SG output's Y or G to the AVI input terminal of VDEC.
• During SG MODE, turn off the blanking 50IRE setup function.
• During VDEC SG output, set the YC seperation setting to NTSC.
• It is possible to use ANALOG OUT MODE together during DIGITAL OUT MODE.
The Main VDEC can output digital color difference, in which colors will appear.
But the route to VDEC input cannot be analysed therefore care should be taken when using.
Depending on the situation, please use the proper analog/digital output.
• The SG MODE outputs color difference and RGB only. Therefore, in the case of CVBS, only the Y input is used resulting in no color.
This is not a damage result nor error.
• The SG MODE's ANA AD RGB (route to input 525i to AD by RGB) as a set's route, the setting does not exist. For this account the
latter part from MVDEC does not have set values, resulting in having funny colors in colorbar, the brightness changes after
switching, etc.
This is not a damage result nor error.
• Depending on MVDEC's part version, ANA_MVDEC_YCBCR may not display colors.
Notes when using SG MODE/SG PATTERN
Operation item
8.2.4.3 SG PATTERN
