Pioneer PDP-507XD Service Manual

PDP-507XD
15
5678
56
7
8
C
D
F
A
B
E
(1) FRONT SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-507XD/WYVIXK5, PDP-507XA/WYVIXK5 and WYV5 are constructed the same except for the following:
Mark
No. Description Part No.
1 50 LED Assy AWW1135
2 LED IR Assy AWW1136
3Front Case Assy See Contrast table (2)
4 Corner Cushion AEB1416
5 Pioneer Name Plate AAM1098
6 Coil Spring ABH1120
7 Blind Cushion AEB1415
8 Nyron Rivet AEC1671
9 Screw Rivet AEC1877
10 Insulation Sheet A AED1283
11 Insulation Sheet B AED1284
12 Power Button AAD4133
13 3P Housing Wire (J130) ADX3424
14 IR Block Cushion AEB1465
15 IR Reducer AAX3455
Mark No. Symbol and Description
PDP-507XD
/WYVIXK5
PDP-507XA
/WYVIXK5
PDP-507XA
/WYV5
3Front Case Assy (507PE/D) AMB2945 Not used Not used
3Front Case Assy (507PE/A) Not used AMB2946 AMB2946

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
