Pioneer PDP-507XD Service Manual

PDP-507XD
36
1234
1234
C
D
F
A
B
E
D 5407,5408 UDZS6R8(B)
MISCELLANEOUS
JA 5401,5402 AKP1278
X 5401 ASS1192
RESISTORS
R 5401–5403 BCN1071
R 5413,5429 RS1/10S0R0J
R 5450 RAB4CQ473J
R 5451 RAB4CQ100J
R 5452,5455 RAB4CQ103J
R 5454 RAB4CQ470J
Other Resistors RS1/16SS###J
CAPACITORS
C 5401,5402 CCSSCH120J50
C 5403,5404,5408,5410 CKSSYF104Z16
C 5405,5407,5452,5473 DCH1201
C 5406,5453 CCSSCH101J50
C 5412,5414,5416,5418 CKSSYF104Z16
C 5423,5426–5428,5430 CKSSYF104Z16
C 5432,5434,5436,5438 CKSSYF104Z16
C 5440,5442,5444,5445 CKSSYF104Z16
C 5447–5451,5455,5457 CKSSYF104Z16
C 5458,5460,5462,5464 CKSSYF104Z16
C 5466,5468,5469,5471 CKSSYF104Z16
C 5472 CKSSYF104Z16
[DSEL BLOCK]
SEMICONDUCTORS
IC 8001 PD6523A
IC 8002 TC74LCX125FT
IC 8003 TC74VCX574FT
MISCELLANEOUS
L 8001–8003 BTX1042
>
F 8004 ATX1058
X 8001 ASS1194
RESISTORS
R 8001,8002 ACN1251
R 8003,8008 RAB4CQ680J
R 8004–8006 BCN1071
R 8009–8011 BCN1067
R 8026,8027 RAB4CQ101J
Other Resistors RS1/16SS###J
CAPACITORS
C 8002 CKSSYB102K50
C 8003,8005,8014–8020 CKSSYF104Z16
C 8025,8027 CKSSYF104Z16
C 8026 DCH1201
[IP BLOCK]
SEMICONDUCTORS
IC 8101 PE5504B
IC 8102,8103 EDS6432AFTA-75-E
MISCELLANEOUS
L 8101–8104 BTX1042
RESISTORS
Mark No. Description Part No.
R 8101–8104,8106–8110 BCN1067
R 8105 BCN1071
R 8111,8116 ACN1246
R 8112–8115,8117 ACN1251
R 8123 RAB4CQ103J
R 8135 RAB4CQ470J
R 8136 RAB4CQ101J
Other Resistors RS1/16SS###J
CAPACITORS
C 8101 CKSSYB102K50
C 8112–8115,8117–8120 CKSSYF104Z16
C 8134–8145 CKSSYF104Z16
[MULTI BLOCK]
SEMICONDUCTORS
IC 8201 PEG121B
IC 8202 AGC1019
IC 8203 TC74VHC08FTS1
MISCELLANEOUS
L 8201–8205 BTX1042
RESISTORS
R 8201–8205 ACN1246
R 8206–8208,8255 ACN1251
R 8209 RS1/10S0R0J
R 8214,8215,8248 RAB4CQ103J
R 8225,8245 BCN1071
R 8246 BCN1073
R 8249 RAB4CQ680J
Other Resistors RS1/16SS###J
CAPACITORS
C 8202 CKSSYB102K50
C 8203–8205 DCH1201
C 8221–8234,8239 CKSSYF104Z16
[IF UCOM BLOCK]
SEMICONDUCTORS
IC 8301 AGC1016
IC 8302 PST9230N
IC 8303 TC74VHC08FTS1
IC 8304 TC7W126FU
IC 8305,8308 TC74VHC00FTS1
IC 8306 MAX3232CPW
IC 8307 TC74VHC125FTS1
Q 8301,8315 DTA124EUA
Q 8302,8307,8312 2SA1586
Q 8303,8304,8306,8308 DTC124EUA
Q 8309,8313 2SC4116
Q 8310,8314 HN1C01FU
Q 8311 2SJ461A
D 8301–8305 1SS355
MISCELLANEOUS
X 8301 ASS1168
X 8302 ASS1172
CN 8301 AKP1213
RESISTORS
R 8307 RAB4CQ473J
R 8348,8351,8352 RAB4CQ103J
R 8354,8356,8358 RS1/16S122J
Mark No. Description Part No.

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
