CN3502 (D16) ↔ 50 ADDRESS S ASSY CN1802 (AD1)
Pin No. Pin Name I/O Function Voltage (V) TP
1NC–Non connection
2
3
–
–
8
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
4 GND – GND
5 V+8V O +8 V power supply input
6 V+8V O +8 V power supply input 8
7 GND – GND –
8 GND_LVDS – GND
9NC–Non connection
10 TAN O LVDS data 1 to 1.4
11 TAP O LVDS data 1 to 1.4
12 NC – Non connection
13 GND_LVDS – GND
14 NC – Non connection
15 TBN O LVDS data 1 to 1.4
16 TBP O LVDS data 1 to 1.4
17 NC – Non connection
18 GND_LVDS – GND
19 NC – Non connection
20 TCN O LVDS data 1 to 1.4
21 TCP O LVDS data 1 to 1.4
22 NC – Non connection
23 GND_LVDS – GND
24 NC – Non connection
25 TCLKN O LVDS data 1 to 1.4
26 TCLKP O LVDS data 1 to 1.4
27 NC – Non connection
28 GND_LVDS – GND
29 NC – Non connection
30 TDN O LVDS data 1 to 1.4
31 TDP O LVDS data 1 to 1.4
32 NC – Non connection
33 GND_LVDS – GND
34 GND – GND
35 V+3.3V O +3.3 V power supply output 3.3
36 V+3.3V O +3.3 V power supply output 3.3
37 GND – GND
38 DIV1 O Data output timing control 0
39 DIV0 O Data output timing control 0
40 GND – GND
ADR_PD I Address PD signal
PSIZE I Panel size judge signal 0
0 to 3.3

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
