Pioneer PDP-507XD Service Manual

PDP-507XD
96
1234
1234
C
D
F
A
B
E
Flowchart of Failure Analysis for The Video System
Has the symptom been settled
when the Digital RF IN terminal
and Input cable are checked?
Poor contact of the terminal part
or input cable is defective.
No
Yes
Has the symptom been settled
when the R07 DT Assy is replaced?
Yes
Has the symptom been settled when the FFC between
CN6003 and CN4013 is checked or replaced?
Has the symptom been settled when the cable between
CN6000 and CN4017 is checked or replaced?
Poor contact of the connector, or
FFC or cable is defective.
Replace FFC or cable.
No
The R07 DT Assy is defective.
Replace the R07 DT Assy.
No
Yes
Yes
Yes
DTV (Digital Terrestrial Video)
doesn't operate.
⇒ DTV
DTV doesn't work
Replace the MAIN Assy.
Is the function corresponding to
selected signal input selected?
Select the corresponding signal
with the input selector.
No

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
