The medical laser shall not be used in areas where the high presence of liquids
is plausible.
In the event of an accidental ingress of a liquid, immediately stop the
procedure, disconnect the power cable and contact PIOON after sales
maintenance for assistance.
Place the main unit of S3 on a suitable table, cart, and shelf top, etc. with a
minimum distance of 20 cm to the surroundings. Attach all items in place in the
following steps.
A. Insert the power cable on the power adapter to the socket which is on the left side
of the main unit.
B. Add the magnetic ring in the adapter packaging box to the output line of the
adapter.
C. Connect one end of the power cord to the power adapter and the other end to the
power supply.
D. Connect the remote door interlock.
Insert the remote door interlock in the port which is on the left side of the unit. The
interlock is potential-free at a maximum 5 VDC and maximum 10 mA. If the remote
interlock is connected to an external port (such as the door contact), it will
immediately shut down the laser beam when the door is opened so that persons
entering the room are not harmed. The device is equipped with a short interlock
connection on delivery.
Remove the short connection and connect it to the remote door interlock.
The electrical system shall correspond to the voltage indicated on the rating
plate or the power supply and in the technical specifications.
Electricity - Electrical shock
Turn off the unit first and unplug its main power supply before installing
the remote door interlock to avoid electrical shock.
