12.
Remove
the
cable
guard
(38)
from
the
underside
of
the
trim
cable
pulleys
(36)
located
in
the
forward
area
of
the
aft
floor
tunnel
by
removing
the
cotter
pin
and
withdrawing
the
roll
pin.
13.
Remove
the
cable
guard
plate
(33)
from
the
underside
of
the
pulley
clus-
ter
(34)
located
in
the
aft
area
of
the
floor
tunnel
by
removing
the
plate
attach-
ment
screws.
14.
Remove
the
cable
guard
fromthe
cable
pulleys
(35)
in
the
aft
lower
sec-
tion
of the
fuselage
forward
of the
cable
turnbuckles
(10
and
11).
15.
With
the
cables
disconnected
from
the
trim
control
wheel,
draw
the
cable(s)
through
the
floor
tunnel.
5-18.
INSTALLATION
OF STABILATOR
TRIM
ASSEMBLY
(FORWARD).
(Refer
to
Figure
5-8.)
a.
The
trim
control
wheel
(1)
with
drum
(3)
may
be
installed
by
the
following
procedure:
1.
Wrap
the
right
trim
cable
(8)
on the
trim
drum
by
inserting
the swaged
ball
of
the
cable
in
the
slot
provided
in the
side
(right
side)
of the
drum
that
mates
with
the
control
wheel,
and
looking
at this
side,
wrap
the
drum
with
three
wraps
of
the
cable
in
a
clockwise
direction.
2.
Attach
the
control
wheel
(1)
to
the
cable
drum
(3)
by
aligning
the
long
lug
of
the
drum
with
the
long
slot
of
the
wheel
and
pushing
the
two
pieces
together.
3.
Wrap
the
left
trim
cable
(9)
on
the
drum
by
inserting
the
swaged
ball
of
the
cable
in
the
slot
provided
in the
flanged
side
(left
side)
of the
drum
and
look-
ing
at
this
side,
wrap
the
drum
with
three
wraps
of the
cable
in
a clockwise
di-
rection.
4.
Lubricate
and
install
the
bushing
in
the
control
wheel
and
drum.
5.
Align
the
control
cables
and
position
the
control
wheel
assembly
be-
tween
its
mounting
brackets
(4).
Ascertain
that
the
end
of
the trim
indicator
wire
(2)
is positioned
in
the
spiraled
slot
of the
drum
(3) with
no bind
on the
end.
In-
stall
the retainer
bolt
(8)
from
the
left
side
and install
washer
and
nut.
AN960-616L
washers
may
be
added
as
necessary
between
the
mounting
bracket
and
the
trim
control
wheel
to
eliminate
end
play.
6.
Install
the
cover
over
the
control
wheel
and
secure
with
screws,
unless
the
control
cables
have
yet
to
be
installed.
b.
The
trim
control
cables
(8 and
9)
may
be
installed
by
the
following
proce-
dure:
1.
Draw
the
cable(s)
through
the
floor
tunnel.
2.
Wrap
the
cable
drum
(3)
and
install
the
trim
control
wheel
as
given
in
step a.
3.
Position
the
cable
pulleys
(6)
on their
mounting
bracket
and
install
the
clevis
pin,
washer
and
cotter
pin
(5).
4.
Connect
the
cable
(8
or 9)
to
the
aft
cable
(12)
at
the
turnbuckle
(10
or
11)
in
the
aft section
of
the
fuselage.
Install
aft cable
(12)
if not
installed.
