TABLE V-III. TROUBLESHOOTING
CHART (SURFACE CONTROLS)
(cont.)
Trouble
Cause Remedy
AILERON
CONTROL
SYSTEM
(cont.)
Control wheels not
synchronized.
Control wheels not hori-
zontal when ailerons
are neutral.
Incorrect aileron
travel.
Incorrect control
column
rigging.
Incorrect
rigging
of
aileron
system.
Aileron control rods
not adjusted properly.
Rig in accordance with
paragraph 5-5 or 5-5B.
Rig in accordance with
paragraph 5-1 1.
Adjust in accordance
with paragraph 5-1 1.
Aileron
bellcrank
stops
not
adjusted
properly.
Adjust
in accordance
with paragraph 5-1 1.
Correct aileron travel
cannot be obtained by
adjusting bellcrank
stops.
Control wheel stops
before
control
surfaces
reach
full
travel.
Incorrect rigging of
aileron
cables,
control
wheel and control rod.
Incorrect
rigging
between
control
wheel
and control cables.
Rig in accordance with
paragraph 5-1 1.
Rig in accordance with
paragraph 5-1 1.
SURFACE
CONTROLS
