ENGLISH
25
#
1-A Damper (x2)
2-A Upper Smoker Cabinet Assembly (x1)
3-A Back Handle (x1)
4-A Cooking Grid (x3)
5-A Cooking Grid Support (x6)
6-A Heat Indicator (x1)
7-A Door Assembly (x1)
8-A Door Latch Assembly (x1)
9-A Door Handle (x1)
10-A Wood Chip Box Lid (x1)
11-A Wood Chip Box Assembly (x1)
11.1-A Wood Chip Box (x1)
11.2-A Wood Chip Box Front Panel (x1)
11.3-A Wood Chip Box Handle (x1)
12-A Control Knob (x1)
13-A Meat Probe (x1)
14-A Lower Smoker Cabinet Assembly (x1)
14.1-A Control Panel & Controller Assembly (x1)
14.2-A Heating Element (x1)
14.3-A Temperature Sensor (x1)
14.4-A Lower Smoker Cabinet (x1)
15-A Water Pan (x1)
16-A Water Pan Support (x1)
17-A Right Rear Leg Assembly (x1)
18-A Left Rear Leg Assembly (x1)
19-A Left Front Leg (x1)
20-A Support Panel (x2)
21-A Back Support Tube (x1)
22-A Right Front Leg (x1)
23-A Bottom Chamber Assembly (x1)
24-A Grease Tray Assembly (x1)
25-A Door Grease Shield (x1)
26-A Power Cord Bracket (x1)
#
A-A 1/4-20*5/8" Screw (x4)
B-A 1/4-20*1/2" Screw (x12)
C-A #10-24*1/2" Screw (x34)
D-A #10-24 Lock Nut (x2)
E-A M5 Spring Washer (x2)
F-A #8-32 Self-tapping Screw (x5)
G-A Spare Hardware
Notes: Due to ongoing product development, parts are subject to change without notice.
