ENGLISH
7
#
1 Damper (x2)
2 Upper Smoker Cabinet Assembly (x1)
3 Back Handle (x1)
4 Cooking Grid (x3)
5 Cooking Grid Support (x6)
6 Heat Indicator (x1)
7 Door Assembly (x1)
8 Door Latch Assembly (x1)
9 Door Handle (x1)
10 Wood Chip Box Lid (x1)
11 Wood Chip Box Assembly (x1)
11.1 Wood Chip Box (x1)
11.2 Wood Chip Box Front Panel (x1)
11.3 Wood Chip Box Handle (x1)
12 Control Knob (x1)
13 Meat Probe (x1)
14 Lower Smoker Cabinet Assembly (x1)
15 Water Pan (x1)
16 Water Pan Support (x1)
17 Right Rear Leg Assembly (x1)
18 Left Rear Leg Assembly (x1)
19 Left Front Leg (x1)
20 Support Panel (x2)
21 Back Support Tube (x1)
22 Right Front Leg (x1)
23 Bottom Chamber Assembly (x1)
24 Grease Tray Assembly (x1)
25 Door Grease Shield (x1)
26 Power Cord Bracket (x1)
#
A 1/4-20*5/8" Screw (x4)
B 1/4-20*1/2" Screw (x12)
C #10-24*1/2" Screw (x34)
D #10-24 Lock Nut (x2)
E M5 Spring Washer (x2)
F #8-32 Self-tapping Screw (x5)
G Spare Hardware
Notes: Due to ongoing product development, parts are subject to change without notice. Contact
Customer Care if parts are missing when assembling the unit.
