ATLAS 20 of 44 User’s Manual
Below are descriptions of the items displayed in the “System” section of the “Dashboard” page.
Name
Description
Site Name
"Site Name" setting value on the web server "Configuration >>
System Settings" page.
Serial Number
Serial number of the chassis/UIM.
UIM Firmware
Firmware version on the UIM.
Webserver Firmware
Firmware version of the web server on the UIM.
Battery Voltage
DC voltage at end of DC cable or the remote battery sense cable.
DC Output Current
Total DC output current of the system.
DC Output Power
Total DC output power of the system.
AC Input Voltage
AC input voltage.
Battery Temperature
Battery pack temperature.
If the "Remote Battery Temperature" setting on the web server
"Configuration >> System Settings" page is enabled then the Battery
Temperature will be displayed if no temperature sensor faults.
If the battery temperature sensor is disconnected or has failed then
"Fault" will be displayed.
If the "Remote Battery Temperature" setting on the web server
"Configuration >> System Settings" page is disabled then "Disabled"
is displayed.
Internal Charger Temperature
Internal charger temperature at the UIM.
Float Voltage Controlled By
Location of float voltage control.
Rotary Switches: rotary switches on the UIM.
Web: settings on the web server "Configuration >> Charge Settings"
page in the "Charge Profile" section.
DC Voltage Sensing
Location of the DC voltage sensing.
Local: charger DC output terminals at the end of the DC cable. This
dependent on proper output cord settings. See if the web server
"Systems Settings" page to setup "DC Cable Gauge" and "DC Cable
Length".
Remote: "REMOTE DC VOLTAGE" input on the UIM. This will be
displayed if the "Remote Battery Voltage" setting on the web server
"Configuration >> System Settings" page is enabled and sensed
properly.
Configured via the "Remote Battery Voltage" setting on the web
server "Configuration >> System Settings" page.
Local (Remote Fault): This will be displayed if the "Remote Battery
Voltage" setting on the web server "Configuration >> System
Settings" page is enabled but not sensed for some reason.
Confirmed Local Presence Time
Remaining
The amount of time remaining in minutes that web server changes
can be made. After this time has expired, the "CONFIRM LOCAL
PRESENCE" button on the UIM must be pressed again to make
additional web server changes.
