FAULT FINDING
FAULT FINDING TABLES
SYMPTOM POSSIBLE CAUSE SOLUTION
The BS is not reading at all.
The Breech Sensors are the wrong way around. Check that the red receiver is on the right-hand side of the breech.
There is a broken wire or contact, or a short circuit on
either of the breech sensor cables.
Check the plug and cables.
Check for cuts or pinches in the sensor cables.
Either sensor is back to front. Check that the sensors face each other when installed.
The Breech Sensor turns itself off after
ring and the display shows the BS
fault icon.
The sensor is dirty. Clean the BS.
The sensor is faulty. Replace the BS units.
The sensor is out of place. Reinstall the BS. Check alignment.
The marker is inconsistent.
The inline regulator is supercharging. Strip and clean the regulator replacing the regulator seal.
The Dwell is too low. Increase the Dwell parameter.
The front SFR is set too low. Increase the front SFR setting.
Poor quality paintballs. Use better quality paintballs.
Poor paintball size to barrel bore match, Use a closer paintball/bore size match.
Inconsistent air supply from air system. Use a better quality air system.
The marker is inefcient.
The Dwell is excessively high. Reduce the Dwell parameter.
LPR is set too high. Reduce the LPR setting.
Poor paintball size to barrel bore match, Use a closer paintball/bore size match.
Low rate of re. The rear SFR is set too low. Increase the rear SFR seting.
Leaking rammer assembly (louder when
bolt is removed).
The front rammer shaft o-ring has deteriorated. Replace the front rammer shaft o-ring.
The marker leaks from the LPR body
vent hole (behind foregrip crown).
LPR piston o-ring or either of the two LPR body o-rings
are damaged or dirty.
Clean and inspect the o-rings. Replace if damaged.
