Planet SGSW-2620 User Manual

- 39 -
Figure 4-51 Filter MAC Address Configuration save successfully screen
Press any key for return to previous menu.
Edit Filter Mac address procedure:
1.Press “Edit”.
2.Choose the MAC address that want to edit and press “Enter”.
3.Press, “Edit” to edit the existence MAC address.
4.After setup completed, press “ESC” and choose “Save” to save the current configuration.
Delete Filter MAC address procedure:
1.Press “Delete”.
2.Choose the MAC address that want to edit and press “Enter”.
3.After setup completed, press “Save” to save the current configuration.
4.4.2.7.3 Previous Menu
Return to Switch Configuration sub-screen.
4.4.2.8 Misc Configuration
From the Switch Configuration sub-screen (see Figure 4-9), highlight Misc Configuration and press
enter. The Misc Configuration sub-screen in Figure 4-52 appears.
Figure 4-52 Misc Configuration screen
