Table 5-8 Descriptions of the SGSW-2620 Port VLAN ID Web Page screen Objects
Description
Port
Select the port by scroll the list in Port column
Port VLAN ID
Enter the port VLAN ID.
Ingress Filter-
ing
Ingress filtering lets frames belonging to a specific VLAN to be forwarded if the port belongs
to that VLAN.
Enable: Forward only packets with VID matching this port's configured VID.
Disable: Disable Ingress filter function
Acceptable
Frame type
Tag Only: Only packet with match VLAN ID can be permission to go through the port.
ALL: Acceptable all Packet
VLAN ID
Range
Select a range of VLAN ID. There are 16 VLAN ID range. The ports are assigned
VLAN ID will be in the same VLAN group.
Apply After setup completed, click “Apply” button to take effect.
Default Reset to factory mode by click “Default” button
