User’s Manual of WGR-500-4P and WGR-500-4PV
17
■ LAN Per 10/100/1000Mbps PoE Port (Port-1 to Port-4) LED
LED Color Function
LNK/ACT Green
Lights:
To indicate the link through that port is successfully established at
10/100Mbps.
Blinks:
To indicate that the switch is actively sending or receiving data over
that port.
PoE In-Use Amber
Lights: To indicate the port is providing 48V~56VDC in-line power.
Blinks: To indicate the connected device is not a PoE powered device (PD).
■ WAN Per 10/100/1000Mbps RJ45 Port (Port-5)
LED Color Function
LNK/ACT Green
Lights:
To indicate the link through that port is successfully established at
10/100/1000Mbps.
Blinks:
To indicate that the switch is actively sending or receiving data over
that port.
