WARNING: Disconnect primary power prior to servicing.
Troubleshooting
6.12.2.7 PS#_JUMP
If a power supply tap fails and the next one available is two or more taps away, a
JUMP fault is triggered and the supply will be shut off and discharged. The only
situations where this could happen are:
• If operating in tap 1 and it fails, having previously failed tap 2.
If tap 2 is being used and fails, and tap 1 and tap 3 have failed previously.
If tap 3 is being used and fails, and tap 2 and tap 4 have failed previously.
6.12.3 Non Critical Power Supply Faults
Non-Critical faults provide indications that there is a problem with the power
supply which is not serious enough to take any immediate transmitter action, but
should be corrected as soon as possible.
6.12.3.1 PS#_TAP#, Power Supply Tap Fault
Detection is based on the level of 50/60 Hz ripple at the output of a two stage, DSP
based, band pass filter in the PS Controller. The BPF is looking at the DC input
voltage data from the PA Power Supply (+52Vdc). It is interpreted as an indication
of a transformer secondary fault which could be a fuse or SCR. If one of the taps has
been detected as faulty the next available Tap (lower ones are the first choice and
the next upper one is the second choice) will be connected depending on
availability.
Note that if the power supply chassis is not properly grounded, or is completely
floating, this induces a considerable amount of 50/60Hz in the voltage sample lines
to the controller so as to erroneously trip this type of fault. The fault is logged as
PS1_TAP1 (up to TAP4) or PS2_TAP1 (up to TAP4). This fault is the same for 3
phase and single phase transmitters.
Table 6-2 on page 6-32 shows the SCRs and fuses on each Rectifier Board
associated with each of the taps. Each transformer has an “A” side and a “B” side
Rectifier Board.
Figure 6-7 on page 6-33 is a component locator for the 3 Phase Rectifier assembly.
It is a top view with the Rectifier Boards oriented horizontally instead of vertically.
Figure 6-8 on page 6-34 is a component locator for the Single Phase power supply
Rectifier assembly.
