WARNING: Disconnect primary power prior to servicing.
Operator Guide
3.4.2 BACK
BACK takes you to the previous layer in the menu tree, not necessarily to the
previous screen. As an example, if you were to press HOME and then choose
STATUS you would now be in layer 2 of the STATUS menu. You should see the
screen shown in Figure 3-5. If you press MORE, you go the the second screen in
layer 2. Now press the BACK key. Notice that it did not take you to the previous
screen but back to Layer 1, the HOME layer, shown in Figure 3-3. However, if
instead of pressing BACK, you pressed more again, this would have taken you to
the first screen in layer 2 (since there are only two screens).
Figure 3-5 Status Layer 2, Page 1
3.4.3 MORE
MORE is a menu item which is used when there are more menu items on a layer
than will fit on one screen. It will take you to the next screen in the same layer.
When you have reached the last screen in that layer, pressing MORE again will take
you back to the first screen in that layer. This is shown on the Diagnostics Display
Menu Tree drawings.
3.4.4 Diagnostic Codes
For ease of discussion a simple code will be used to guide you to the area or screen
being discussed. The code will have the name of one of the HOME menu items
listed above, followed by the appropriate A, B, C or D function key presses required
to get to the screen being discussed. The code will always be enclosed in brakets
[x,x,x].
NOTE:
It will be assumed that you always press the HOME key first before entering
the key sequences in the brackets.
