NFC
NFC feature is enabled by default. But if NFC does not work, make sure the NFC is enabled from
the Quick setting panel.
PM75around the battery cover release button. Bring the NFC tag close to
the battery cover release button (Rear-upper side of the device) as below.
NFC Tagging Area
Figure 87 PM75 NFC tagging area
Figure 86 Turn on NFC in Quick setting panel
Figure 88 Tagging NFC tag
