4.3. Appearance of the device IL
Below is a photo of ILW 15 - capacity 115l with a description of the essential components of the device.
Front view
1) Rating plate
2) Chamber fan
3) Internal glass door
4) Access port Ø30mm for external sensor
5) Condenser cover
6) Wheels with break
7) USB port
8) Touch screen
9) Door sensor
10) Shelf
11) External door
