45
5.8. Data record
Register window (Figure 24) contains the following information:
• Time of sample registration [date],
• Temperature value from the main sensor in the chamber [temp.].
Each User can have 10 000 data records to use for the max period of 6 months. If all the memory cells are full,
the oldest ones are overwritten. Data is displayed in the chronological order from the oldest to the latest record.
It is possible to segregate data according to the selected column. To do so, click the column heading.
The samples are only registered when the program is running. The frequency of registration depends on the
program parameters settings, see » page 31 .
The time of opening the Data Register depends on the number of saved samples. The larger
number of stored cells increases the opening time of the window. Then, a progress window will
appear (Figure 23), indicating what date range has been displayed. By clicking on you can
stop loading and overview only some part of the data. By pressing the progress bar, you can
minimize it (it will appear at the top of the screen) and overview the previously loaded data.
