6. MODBUS TCP interface
Connection parameters:
IP address: the same as devices (set in the Network panel » page 54)
port: 502
register INPUT REGISTERS
function READ_INPUT_REGISTERS (0x30001)
Address
Type
Multiplier
Description
0
int
10
temperature from the main sensor
1
int
10
temperature from the additional sensor (option)
2
int
10
humidity (option)
3
bool
-
door open
4
bit
-
b0 – door alarm
b1 - upper temperature alarm
b2 - lower temperature alarm
b3 - over Protection
b4 - under Protection
b5 – main sensor error
b6 – additional sensor error
b7 – protection sensor error
b8 – temperature sensors error
b9 – humidity sensor error
b10 – hardware error
b11 - MRW error
