58
7. COMPONENTS OF THE DEVICE
7.1. Internal glass door
To open or close the internal glass door use the plastic handle installed on the glass. While operating the unit
at high temperatures, do not touch the glass door or inner parts of the chamber.
7.2. Door lock
All units have been equipped with a door lock located in the door handle.
Two keys are attached on the backside of the device.
7.3. Access port
A Ø30 mm access port can be used to insert an external temperature sensor, which has been secured with
a silicon plug. The plug should cover the access port while the unit is operating. If multiple cables have been
inserted through the access port and if it is not possible to use the plug, secure the access port with adhesive
tape. If you leave the access port open, it may affect temperature stability and uniformity within the chamber.
