Polaris 2010 Ranger RZR 800 EFI User Manual

4.5
ELECTRONIC FUEL INJECTION
4
P
RELIMINARY
V
ERS
I
ON
EFI System Exploded View
1. Electronic Control Unit (ECU)
2. Intake Air Temperature / Barometric Air Pressure Sensor (T-BAP)
3. Crankshaft Position Sensor (CPS)
4. Fuel Injectors
5. Fuel Filter
6. Fuel Pump / Regulator / Gauge Sender Asm. (Located in tank as an assembly)
7. Fuel Rail
8. Engine Coolant Sensor (ECT)
9. Throttle Position Sensor (TPS)
10. Throttle Body
11. Ignition Coil
12. Spark Plugs
1
2
3
4
5
6
7
8
9
10
11
12

Polaris 2010 Ranger RZR 800 EFI Specifications

General

Brand	Polaris
Model	2010 Ranger RZR 800 EFI
Category	Utility Vehicle
Language	English
