4.8
ELECTRONIC FUEL INJECTION
P
RELIMINARY
V
ERS
I
ON
FUEL TANK
Exploded View
Rear
Tank Bracket
Screw
Pad
Fuel Tank
Front
Tank Bracket
Gasket
Cap
Hi-Temp
Flex Conduit
Fuel Pump Asm
Screw
Pad
Quick Connect
Fuel Line
Fuel Flow
Fuel Filters
Fuel Pump Assembly
Quick Connect Fuel Line
Fuel Rail
Fuel Injectors
Pressure Regulator
Fuel Tank
