Dash Instruments / Controls (RZR S INT’L)
C
D
E
F
B
A
I
G
H
K
J
A
C
D
E
F
H
L
G
A. Instrument Cluster
B. Headlight Switch (MY09)
C. 2WD/AWD/TURF Switch
D. 12 Volt Accessory Receptacle
E. Speedometer “Mode” Button
F. Key Switch
G. Hazard Switch
H. Turn Indicator
I. Horn (MY09)
J. Turn Signal Switch (MY09)
K. Turn Signal Cover (MY09)
L. Switch; Turn, Lights, Horn (MY10)
MODEL YEAR 2010
Dash Instruments
MODEL YEAR 2009
Dash Instruments
