3.24
ENGINE
P
RELIMINARY
V
ERS
I
ON
ENGINE DISASSEMBLY AND INSPECTION
Cylinder Head Assembly Exploded View
Push Rods
Hydraulic Lifters
Valves
Cylinder Head
Valve Seals
Springs
Spring Retainers
Rocker Arms
Retainer Locks (keepers)
Valve Spring Seats
