4.24
ELECTRONIC FUEL INJECTION
P
RELIMINARY
V
ERS
I
ON
IMPORTANT: Take care not to place any excessive
force on the filler neck
11. Remove the (2) tank bracket fasteners that retain the fuel
tank in the chassis.
12. Lift the rear of the fuel tank up first and carefully pull it out
from the vehicle.
Fuel Tank Installation
1. Carefully reinstall the fuel tank assembly.
2. Reinstall the (2) tank brackets and fasteners.
3. Reinstall the rear RH fender well and secure with fasteners.
4. Reinstall the seat belt mechanism and secure the lower bolt.
5. Reinstall the RH rocker panel and all (15) fasteners.
6. Reinstall the rear seat base and secure with the (2) fasteners.
7. Reinstall the push rivets into the rear of the center console.
8. Install the fuel line and vent hose and verify they are secure.
9. Reconnect the fuel pump electrical harness.
10. Reconnect the negative battery cable. Test the fuel pump
by turning on the key and listening for the pump to activate.
11. Finally, install the rear service panel along with the driver
and passenger seats.
Tank Bracket
Fasteners
