9924871 R03 - 2014 Polaris Sportsman® 570 EFI Service Manual
© Copyright 2013 Polaris Sales Inc.
Mud Guard Removal / Installation
1. Remove front bumper as outline in this chapter.
2. Locate the mud guards in the front wheel area.
3. Remove the (1) T27 bolt and the (3) plastic rivets per
side.
4. Remove the wheel well from the vehicle frame.
5. Reverse this procedure to reinstall the mud guards.
6. Torque the T27 fasteners to specification.
T27 Fasteners:
4-6 ft-lbs (6-8 Nm)
BODY / STEERING / SUSPENSION
