3 First Steps
Back view
The back view of the sensor head is shown in the following figure.
Figure 3.2: Back view of the sensor head
1 TRANSPORT LOCK
transport lock
To secure the linear stage to protect the sensor head during transport.
2
Name plate
Plate with information on model, serial number, power specifications etc.
