Potterton Paramount four - Diagnostics Cascade;Heat Generation;Consumers

End user (Eu) Commissioning, Engineer (menu
Status)
Charg el imm heater El charg, emergency mode
El charg, source protection
Electric charging defrost
Electric charging, forced
Electric charging, substitute
Charging restricted Charging locked
Restricted, HW priority
Charging active Forced charging active
Partial charging active
Recooling active Recooling via collector
Recooling via HW/CHs
Charged Charged, max st tank temp
Charged, max charging temp
Charged, forced temp
Charged, required temp
Part charged, required temp
Charged, min charging temp
Cold Cold
No request No request
Tab.34 Status table swimming pool
The following messages are possible under Swimming pool:
End user (Eu) Commissioning, Engineer (menu
Status)
Manual control active Manual control active
Fault Fault
Heating mode restricted Heating mode source
Heated, max swi pool temp Heated, max swi pool temp
Heated Heated, setpoint solar
Heated, setpoint source
Heating mode Heating mode solar off
Heating mode source off
Cold Cold
9.2.24 Diagnostics cascade/heat generation/consumers
Diagnostics cascade/heat generation/consumers (8100-9058)
Displays of different setpoint and actual values, relay switching statuses
and counter statuses for diagnosis purposes.
Gas energy
There are 6 energy meters available, comprising the estimated gas energy
used with the aid of the fan speed and a linear approximation of the actual
burner output. The energy meters must be switched on and off using
prog.no. 2550. The results can be corrected under prog.no. 2551.
2 overall meters can be reset on the engineer level:
Prog.no. 8378: Overall gas energy heating
Prog.no. 8379: Overall gas energy DHW
The end consumer can reset 2 meters:
9 Settings
126 Paramount four 30 – 115 kW 7658013 - 02 - 15092016
