Potterton Paramount four - Tables of Sensor Values

Model Para‐
mount
four 30
Para‐
mount
four 40
Para‐
mount
four 50
Para‐
mount
four 60
Para‐
mount
four 80
Para‐
mount
four 95
Para‐
mount
four 115
Max. delivery pressure at flue gas
outlet
mbar 1,1 1,1 1,1 1,1 1,1 1,5 1,8
Flue gas/air supply
duct
mm 110 / 160
Flue gas value group to DVGW G636 – G6
Heating water
Adjustment range heating water temperature °C 20 - 85 20 - 85 20 - 85 20 - 85 20 - 85 20 - 85 20 - 85
Max. flow temperature °C 100
Water operating pres
sure
min. bar 1,0 1,0 1,0 1,0 1,0 1,0 1,0
MPa 0,1 0,1 0,1 0,1 0,1 0,1 0,1
max. bar 3.0 3,0 4,0 4,0 4,0 4,0 4,0
MPa 0,3 0,4 0,4 0,4 0,4 0,4 0,4
Gas connected loads
Supply pressure for natural gas mbar G20: min. 17 - max. 25
Connection values Natural gas E [H
UB
9,45 kWh/m³]
m³/h 0,59 -
3,2
0.95 -
4.0
1,06 -
5,30
1,48 -
6,10
2,22 -
8,10
2,12 -
10,10
2,65 -
12,20
Natural gas LL [H
UB
8,13 kWh/m³]
m³/h 0,69 -
3,7
1,11 -
4,7
1,23 -
6,20
1,72 -
7,10
2,58 -
9,50
2,46 -
11,70
3,08 -
14,10
Connection pressure for propane mbar min. 25 - max. 45
Propane [H
U
12,87
kWh/kg]
kg/h 0,44 -
2,33
0,70 -
2,95
0,93 -
3,89
1,09 -
4,51
1,63 -
5,98
2,33 -
7,38
2,72 -
8,94
Propane [H
U
24,64
kWh/m³]
m³/h 0,23 -
1,22
0,37 -
1,54
0,49 -
2,03
0,57 -
2,35
0,85 -
3,13
1,22 -
3,86
1,42 -
4,67
Electrical power consumption
Electrical connection V/Hz 230 V / 50 Hz
Max. electr. power consumption W 55 70 88 100 108 160 200
Heating mode Protection W 3 3 3 3 3 3 3
Dimensions
Weight of boiler kg 53 53 61 61 72 84 84
Boiler water content l 3,6 3,6 4,7 4,7 5,8 7,8 7,8
Height mm 852
Width mm 480
Depth mm 407 407 447 447 542 570 570
Connections
Gas connection 3/4" 1"
Heating flow 1"
1
1
/
2
”
Heating return 1"
1
1
/
2
”
3.2.4 Tables of sensor values
Tab.5 Resistance values for outside temperature sensor ATF
Temperature [°C] Resistance [Ω]
-20 8194
-15 6256
3 Technical specifications
7658013 - 02 - 15092016 Paramount four 30 – 115 kW 15
