U Below windows or openings on pitched roofs. 2000 mm
(1) In addition, the terminal should be no nearer than 150 mm to an opening in the building fabric formed for the purpose of accommodating
a built-in element such as a window frame.
(2) Only one 25 mm clearance is allowed per installation. If one of the dimensions D, E, F, G or H is 25 mm then the remainder MUST be as
shown in brackets, in accordance with BS 5440-1
6.3.6 Chimneys already in use
If a chimney used before for oil or solid fuel-fired boilers is used as a shaft
for installation of a concentric exhaust gas pipeline, the chimney must be
thoroughly cleaned first by a specialist.
Note
The concentric flue gas pipe must run straight in the duct.
Height above the roof
With regard to the minimum height above the roof, country-
specific regulations regarding chimneys and flue gas systems
are applicable.
6.3.7 Cleaning and inspection openings
Danger
Clean exhaust gas pipelines!
It should be possible to clean the flue gas pipes and inspect their
free cross-section and leakproofness.
At least one cleaning and inspection opening must be installed in the in
stallation room of the Paramount four.
Exhaust gas pipes in buildings, which cannot be cleaned or inspected from
their port side must have an additional cleaning port in the upper part of
the exhaust system or above the roof.
The exhaust gas pipelines at the outer wall must have at least one clean
ing opening in the lower part of the exhaust gas facility. For exhaust gas
facilities with building heights of < 15.00 m in the vertical section, a pipe
line length of < 2,00 m in the horizontal section and a maximum pipeline
diameter of 150 mm with a maximum deflection (except for deflection di
rectly at the boiler and in the shaft) one cleaning and inspection opening in
the installation room of the Paramount four is sufficient.
The ducts for exhaust gas facilities must not have any openings other than
the necessary cleaning and inspection ports as well as openings for back
ventilation of the exhaust gas pipe.
6.4 Electrical connections
6.4.1 Electrical connection (general)
Danger
Danger to life through incorrect work!
All electrical work in connection with the installation may only be
carried out by a trained electrician.
Mains supply AC 230 V +6% -10%, 50 Hz
In UK follow the relevant regulations.
The electrical connection should be made with correct and non-reversible
polarity. In Germany the connection can be executed as an accessible
plug and socket connection with non-reversible polarity or as a fixed con
nection. In all other countries, a fixed connection must be provided.
For the power supply, use the power cable attached to the boiler or cable
types H05VV-F 3 x 1 mm
2
or 3 x 1.5 mm
2
. The earthing cable must be lon
ger at the connection in order to guarantee that this connection is the last
cable to rupture in the event of a hazard.
6 Installation
7658013 - 02 - 15092016 Paramount four 30 – 115 kW 41
