Diagnostics consumers Prog. no. Level Standard value
Relay output QX22 module 1
Off | On
9051 C
Relay output QX23 module 1
Off | On
9052 C
Relay output QX21 module 2
Off | On
9053 C
Relay output QX22 module 2
Off | On
9054 C
Relay output QX23 module 2
Off | On
9055 C
Burner control Prog. no. Level Standard value
Prepurge time 9500 E 15 s
Required output prepurging
(1)
9504 E Paramount four 30:
14,5 kW; Paramount
four 40: 19.5 kW
Paramount four 50:
32,0 kW; Paramount
four 60: 35,0 kW; Pa‐
ramount four 80: 50,0
kW; Paramount four
95: 50,8 kW; Para‐
mount four 115: 56.6
kW
Required output ignition
1)
9512 E Paramount four 30:
14,5 kW; Paramount
four 40: 19.5 kW
Paramount four 50:
32,0 kW; Paramount
four 60: 35,0 kW; Pa‐
ramount four 80: 50,0
kW; Paramount four
95: 50,8 kW; Para‐
mount four 115: 56.6
kW
Required output LF
1)
9524 E Paramount four 30:
5,6 kW; Paramount
four 40: 9.0 kW
Paramount four 50:
10,0 kW; Paramount
four 60: 14,0 kW; Pa‐
ramount four 80: 21,0
kW; Paramount four
95: 20,0 kW; Para‐
mount four 115: 25.0
kW
Required output HF
1)
9529 E Paramount four 30:
30,0 kW; Paramount
four 40: 38.0 kW
Paramount four 50:
50,0 kW; Paramount
four 60: 58,0 kW; Pa‐
ramount four 80: 77,0
kW; Paramount four
95: 95,0 kW; Para‐
mount four 115:
115,0 kW
Postpurge time 9540 E 10 s
9 Settings
78 Paramount four 30 – 115 kW 7658013 - 02 - 15092016
