Power Measurement ION 8000 Series User Manual

ION 8000 Series User Guide Modbus Slave Modules
Chapter 7 - Third Party Protocols Page 101
kW/kVAr/kVA
Format: signed 32 bit InZero: -1,000,000,000
Base Address: 40198 InFull: 1,000,000,000
Scaling: No OutZero: -1,000,000
OutFull: 1,000,000
Input Modbus Registers Parameter
Source #1 40198 to 40199 kW a
Source #2 40200 to 40201 kW b
Source #3 40202 to 40203 kW c
Source #4 40204 to 40205 kW tot
Source #5 40206 to 40207 kW tot max
Source #6 40208 to 40209 kVAR a
Source #7 40210 to 40211 kVAR b
Source #8 40212 to 40213 kVAR c
Source #9 40214 to 40215 kVAR tot
Source #10 40216 to 40217 kVAR tot max
Source #11 40218 to 40219 kVA a
Source #12 40220 to 40221 kVA b
Source #13 40222 to 40223 kVA c
Source #14 40224 to 40225 kVA tot
Source #15 40226 to 40227 kVA tot max
Source #16 40228 to 40229
