Configuring Data Logging ION 8000 Series User Guide
Page 142 Chapter 12 - Logging
Changing the Parameters that are Logged
The meter’s factory configuration logs a comprehensive set of energy, power and
harmonics parameters. You cannot change which parameters are logged by
configuring a setup register. If you are comfortable editing module links, you can
change the logged parameters by linking the output registers you want logged to
the inputs of an Data Recorder module.
NOTE
Adding or deleting a log’s parameters is an advanced procedure, as it requires changes to the links
between modules; use Designer (refer to the Designer section of the online
ION Enterprise Help) or ION
Setup.
Changing Waveform Recording
The Waveform Recorder modules do not require changes to their default settings.
If you want to change the format of the recorded waveforms, refer to the
Waveform Recorder module description in the ION Reference.
Default Logging Capacity
The default settings allow for a maximum time logging capacity of about 35 days
for the ION 8000 series meters. The following table summarizes the default
recording depths and recording intervals of the various Data recorders and
Waveform recorders in the meter.
Changing the Log Depths
Change the value in the Data Recorder’s Depth setup register to increase the
number of records stored in the recorder. The RecordMode setup register controls
how the Data Recorder will overwrite old records; refer to the Data Recorder
module description in the online ION Reference before changing this setup register.
Log Types
ION 8300
Default Depth
ION 8400
Default Depth
ION 8500
Default Depth
Interval
Energy Logs
Revenue Log 3360 3360 3360 900 seconds
Loss Log N/A 3360 3360 900 seconds
EgyDmd Log N/A 1350 3360 900 seconds
Time of Use Logs TOU Logs N/A 50 50 Triggered on demand
Historic Logs Hist Logs N/A N/A 3360 900 seconds
Harmonic Logs Harm Logs N/A N/A 840 3600
Disturbance Recorders Transi ent Log N/A N/A 100 Triggered on demand
Sag/Swell Log 100 100 100 Triggered on demand
EN50160 Logs (ION 8500 only) N/A N/A 10 Daily, weekly, 10 min...
