41
www.powerbox-systems.com
4.1.1. Size
With these three buttons you can adjust the size of the widgets:
Small, Medium and Large.
4.1.2. Delete Widget
You can delete the widget with this button.
4.1.3. Rescan Sensors
You will need this function if you connect new sensors when the system is already running. The process gathers all sensor infor-
mation on the P²-BUS. Basically, all sensor information is automatically collected when the system is switched on.
4.1.4. + Button
At this point you can select sensor values using the + button. Each widget can display multiple sensor values, even from sepa-
rate sensors; the values then alternate in the widget’s display. This is accomplished by selecting one or more sensor values which
you want to appear in your widget, and pressing OK to confirm.
The left-hand column shows all the connected sensors, while the right-hand column shows all the values which these sensors
supply. The P²BUS is an in-house development, and is capable of transmitting up to 255 sensors each with 32 individual
values – and at a speed of up to 800 values per second!
At this point you can select which sensor value this widget is to display, and press OK to confirm your choice. It is possible to
set up each widget to display multiple sensor values, even from different sensors; these values are then displayed in turn by the
widget. This is accomplished by selecting one or more sensor values which you want your widget to display, then confirming your
choice with OK.
The selected sensor value now appears in the list. In the example below several sensor values have already been selected.
