18
PowerBox-Systems − World Leaders in RC Power Supply Systems
It is possible to adjust settings such as channel shift,
frame rate, iGyroSAT and others at the receiver itself.
These settings are usually accessed using a Telemetry
widget, but are also available if you press the receiver
image in the Bind menu.
NOTE
3.4.4. Selecting ATOM/M-Link
If your transmitter is equipped with a supplementary Multi-
plex M-Link aerial, you will find the button for switching from
the ATOM system to the M-Link system right at the top.
The M-Link system offers two binding modes:
Bind 12K
14ms frame rate, 12 channels
Bind 16K
21ms frame rate, 16 channels
Choose your setting. If you do not need more than twelve channels, you should always give preference to Option 12K, as the
servos are addressed at a higher rate in this mode. This can be advantageous in respect of smooth running, transit speed and
precision. In contrast, Option 16K offers sixteen channels and a slower frame rate; this is the best choice for use with older
servos.
Your choice applies to the current model, and is stored in the model file together with the relevant Bind information. If you change
the setting for a model which has already been bound, you will need to re-bind the receiver!
3.5 Differential
The Differential function is a simple method of setting up differential aileron travel. It is possible to set differential as a fixed value,
assign it to any transmitter control or trim, and also set different levels for individual flight phases. These features enable you to
adjust the degree of differential accurately in flight. To set up differential, select the Differential menu point, and you will see this
screen display. Press the + button, and select from the list the function to which the differential should apply:
