powersoft K10 DSP+AESOP User Manual

▶
9
K Series User Guide
FIGURE 3: K2/K3 4-port version rear panel
Mains plug
Air vents
Channel 2 analog input or AES3
(depending on the position of the AES/EBU-
Analog button)
Channel 2
output
Channel 1
output
Channel 1 analog input
Channel 2 AES/EBU or analog input
selection button
(functional only for devices with retrofitted DSP and/or
KAESOP board)
Channel 1 and 2 output link
selection button
RS485 port +
aux voltage
Serial remote ID
selection
FIGURE 4: K6/K8/K10/K20 2-port version rear panel
CLASS2
WIRING
Mains plug
Air vents
Ethernet +
AESOP ports
External
aux voltage
Channel 2 analog input or AES3
(depending on the position of the AES/EBU-
Analog button)
Channel 2 physical
link through output
Channel 2
output
Channel 1
output
Channel 1 physical
link through output
Channel 1 analog input
Channel 2 AES/EBU or analog
input selection button
Channel 1 and 2 output link
selection button
