Physical Features
The Powerware 9170
+
UPS is available in four cabinet sizes. Figure 1
through Figure 6 show the 3-slot and 9-slot configurations and identify
basic Powerware 9170
+
system features. Six-slot and 12-slot cabinets are
also available; external battery cabinets are available in 6-, 9-, and 12-slot
sizes.
Front Panel
Display
Front Cover
Panel
Figure 1. Three-Slot Cabinet (Front View)
Communication
Slots
Power Outlets
(optional)
Input Power
Cable (optional)
DB-9
Communication
Port
Figure 2. Three-Slot Cabinet (Rear View)
