Location Requirements
Install the Powerware 9170
+
UPS as close as possible to the equipment or
the load distribution panel it will protect. If this distance is more than
25 ft (7.6m), transient noise can reappear in the electrical distribution
system.
If a separate external battery cabinet is installed, the battery cabinets
must be adjacent to the Powerware 9170
+
UPS. If the batteries will be
further from the unit than the standard cables allow, contact your service
representative or your local distributor for assistance.
UPS Setup
The Powerware 9170
+
UPS is shipped in a carton on a shipping pallet.
Power and battery modules are shipped in separate boxes on another
pallet. Three-slot cabinets and modules are shipped on one pallet. Refer
to the unpacking instruction sheet (LTS-1724) packed inside the UPS
shipping carton.
NOTE Verify that all Powerware 9170
+
UPS power modules are th e
proper type for the UPS cabinet: Split-phase power modules have brown
labels; universal (single-phase) power modules have black labels. Do not
mix brown and black modules in the same UPS cabinet.
Three- and Six-Slot Cabinets
NOTE Do not attempt to lift the cabinet by the module shelves or other
convenient edges or panels.
1. If an optional caster cart is included for cabinet mobility, see
“Caster Cart Installation” on page 10 for information about
mounting the cabinet on the cart and stabilizing it using the cart
foot pads.
2. After placing the cabinet in its intend ed operating location, cut
the lifting straps or slip them off the cabinet base tabs.
