Table 12 contains a description of all alarm log messages.
Table 12. Alarm Log Messages
Message Explanation
Open Cell Battery failure caused by open cell.
Weak Battery Battery failure caused by load test.
Phase Error Internal error – contact your service representative.
Module Failure Internal error – contact your service representative.
Excessive Transfers Internal error – contact your service representative.
Precharge Failure Internal error – contact your service representative.
Insufficient Batteries Too few battery modules; decrease load or add battery
modules.
Insufficient Modules Too few power modules; decrease load or add power
modules.
Incompatible
Module
A power module with incompatible firmware has been
installed in the system; contact your service representative.
Battery Test
NOTE The batteries must be fully charged and the UPS must not have
been on battery within 24 hours of the battery test.
The Powerware 9170
+
has a battery test that runs automatically every
30 days by default and can also be performed manually.
The battery test parameters, including the test interval and time of day,
can be set up in menu 3, submenu 1. To initiate a manual test, select
menu 3 1 1. When the test is complete, the UPS automatically provides
the results on the screen.
Menu Map
Figure 60 is an illustr a tion of how to access all Powerware 9170
+
system
parameters. The menu structure has 6 primary-level menus, named
System Status Menu (1) through Service Menu (6). Under each primary
menu are secondary items, each numbered by its location under the
primary menu. Use the various buttons as shown in the map to navigate
to the desired parameter.
