Moving the Cabinets
CAUTION
Do NOT attempt to raise the cabinet with the power or battery modules
installed.
The Powerware 9170
+
UPS and the battery cabinet are very heavy with
power and battery modules installed. Before moving the cabinets,
remove the power and battery modules. Move the modules separately
from the cabinets.
The 3- and 6-slot cabinets may be ordered with a caster cart to enable
moving the cabinet. “Caster Cart Installation” on page 10 describes how
to set the four foot pads on this cart to keep the cabinet from rolling
when properly positioned.
The 9- and 12-slot cabinets have casters built into the cabinet base. Use
thefollowingproceduretoraisethecabinetbeforerollingitonits
casters.
1. Ensure that the cabinet contains no power or battery modules.
2. For 12-slot cabinets with non-isolated output only. Slide the
cabinet base out from under the stabilizer brackets in the rear
section of the cabinet base.
Remove the stabilizer brackets from the floor/wall. Follow the
instructions in “Stabilizer Bracket Installation” on page 11 to
reinstall the stabilizer brackets in the new location.
3. Locate the f our plastic caps covering the caster bolts. They are
at the corners of the cabinet base.
4. Pry the caps out of the bolt access holes.
5. Use a 1/2I hex-style socket wrench to turn each of the four
bolts clockwise. Doing so lowers the casters to allow the cabinet
to roll on the casters .
