System Wiring Diagrams
Select wiring diagrams from Table 5 based upon the installation voltage.
Table 5. UPS with Bypass Wiring Diagrams for Non-Isolated Output
UPS In
p
ut UPS Out
p
ut
O
u
t
p
u
t
W
i
r
e
s
Wiring Diagrams
U
P
S
I
n
p
u
t
Voltage
U
P
S
O
u
t
p
u
t
Voltage
Output Wires
Input Output System
100/200
110/220
120/208
120/240
127/220
100/200
110/220
120/208
120/240
127/220
L1, L2, N*
Figure 18a on
page 29
Figure 19 on
page 30
Figure 22 on
page 34
200
208
220
230
240
200
208
220
230
240
L1 – L2
Figure 18b on
page 29
Figure 20 on
page 30
Figure 23 on
page 34
220
230
240
220
230
240
L1 – N
Figure 18b on
page 29
Figure 20 on
page 30
Figure 24 on
page 35
*Split-phase power modules required.
