Power and Battery Module Installation
Use the following procedure to install the power and battery modules
into the Powerware 9170
+
cabinet:
1. Remove the front cover panel(s) of the cabinet.
The panels have spring latches on the left and right sides that
hold them in place.
NOTE Place battery modules below all power modules in the UPS
cabinet. Two battery modules (side-by-side ) are required to complete each
battery string.
2. Insert the battery modules into the cabinet.
Push each module firmly until the front latch snaps to secure
the battery module (see Figure 48). Repeat for each additional
battery module.
NOTE All power modules in the Powerware 9170
+
UPS cabinet must be
of the same type: Split-phase power modules have brown labels;
universal (single-phase) power modules have black labels. Do not mix
brown and black modules in the same UPS cabinet.
NOTE Do NOT install more than seven power and/or optional battery
charger modules in the system.
3. Insert the power modules into the upper slots of the cabinet. To
insert a power module:
Lower the front down slightly and lift the rear edge over the
safety stop on the center support rail. Keep the module handle
extended until the module is fully inserted (see Figure 48).
Raisethepowermodulehandletosecurethemoduleintothe
cabinet. Be sure the handle latch snaps into place. Tighten the
thumbscrew on the handle.
