PR POWER PR4000 - Hydraulic Gear Box

PR4000 9mt 4x1000W METAL HALIDE
12
TL073-11-02-03
01-02-2011
9.3 HYDRAULIC GEAR BOX
9.3.1 ELECTRICAL MOTOR
Feeding
240 V 50-60 Hz ± 10%
Power
0,55 kW
Poles
4
Duty factor
S1
9.3.2 GEAR PUMP
Displacement
1,3 cm
3
Maximum pressure
210 bar
Factory setting pressure
180 bar
Emergency action system
Manual
9.3.3 UNLOADING SOLENOID VALVE
Coil thermal insulation
Class F – VDE0585
Electric connection
DIN 43650-A / ISO 4400
Protection degree
IP 65
Coil duty cicle
ED 100%
Coil voltage
230 V 50-60 Hz ± 10%
9.3.4 HYDRAULIC FLUID
Reservoir capacity
5 l
Fluid type
ISO/DIN 6743/4 mineral oil
Fluid viscosity
15-100 mm
2
sec – ISO 3448
Fluid temperature
-15°C ÷ +80°C
Fluid maximum contamination level
Class 10 in accordance with NAS
1638 with filter B 25 > 75
