PR4000 9mt 4x1000W METAL HALIDE
TL073-11-02-03
01-02-2011
Rotate the mast on the opportune way to place the lighting beam in the desiderate position. For
simplify the rotation they are predisposed two handles (Fig. 9-A).
Pull the locking pin of the mast (Fig. 9-B) in way to concur the rotation of it. The blocking happens
re-inserting the pin in one of the many centers predisposed along the sping ring. The mechanical
block concurs to stop the spin to 340°.
(Fig. 9)
WARNING: it is strictly prohibited to close the stabilizers when the lighting tower is in
vertical position at the maximum height.
WARNING: the lighting tower is prearranged to withstand 110 km/h wind at the maximum
height. In case of using in windly places, be careful and lower timely the telescopic mast.
In case of hydraulic gear box or generating set engine‘s failure, it is possible to lower the mast.
Make reference to the chapter “12.2 HYDRAULIC GEAR BOX”.
13.11 STOPPING THE ENGINE
Switch off all the lamps through the circuit breakers (32-33-35-36).
Wait that the engine works in these conditions for approximately 1 minute, then turn the starting
key (29) to the stop position.
In emergency case it is possible to stop the generating set by pressing the stop button (19).
