Treadmill Base Operation
Input Power
The GEN-06 / TRM10
1
base is equipped with a removable line cord plugged into a power
entry socket. This is designed to accommodate either 120 VAC
2
or 240 VAC NEMA com-
patible line cords, as well as line cords for other countries. The diagram below shows a NEMA
20A plug for both 120 VAC and 240 VAC configurations in the United States.
1
TRM800 version 1 treadmills mfg. dates 2010 thru 2014.
2
voltage in an alternating current circuit
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 128
9 Theory of Operation
